General Spec

• Product Number: CS31CM
• ANSI/TIA Category: 6
• Cable Component Type: Horizontal
• Cable Type: U/UTP (unshielded)
• Conductor Type, singles: Solid
• Conductors, quantity: 8
• Jacket Color: Blue
• Pairs, quantity: 4
• Transmission Standards: ANSI/TIA-568.2-D | CENELEC EN 50288-6-1 | ISO/IEC 11801 Class E

Dimesions

• Cable Length: 304.8 m | 1000 ft
• Diameter Over Insulated Conductor: 1.029 mm | 0.0405 in
• Diameter Over Jacket, nominal: 6.401 mm | 0.252 in
• Conductor Gauge, singles: 23 AWG

Electrical Specifications

• Operating Voltage, maximum: 80V
• Remote Powering: Fully complies with the recommendations set forth by IEEE 802.3bt (Type 4) for the safe delivery of power over LAN cable when installed according to ISO/IEC 14763-2, CENELEC EN 50174-1, CENELEC EN 50174-2 or TIA TSB-184-A

Material Specifications

• Conductor Material: Bare copper
• Insulation Material: Polyolefin
• Jacket Material: PVC
